ELECTRICAL
Lithium Battery

Advantages of TDR Lithium Iron Phosphate (LiFePO4) Battery:
- Cold Temperature Performance: Outstanding cold crank power that outperforms other products.
- Dynamic Charge Acceptence: Super-fast charging rate through high current.
- Low Self-discharge: Able to start the vehicle after 12 months' storage.
- Lighter Weight: Up to 60% lighter than comparable lead acid batteries, suitable for racing bike.
- Robust Brass Terminal: Offer an enhanced electrical and mechanical performance.
- Heat Resistance: 230C high temperature resistance formulated flame retardant case.
- Waterproof Design: Silicone sealant makes excellent sealing perfromance.
- Safety & Social Responsibility: No toxic, no acid fill, no lead risk, environment friendly.

- Lithium Iron Phosphate | Extensive Cycle Life - More than 4X Longer life than lead-acid battery.

TDR Lithium Iron Phosphate (LiFePO4) Battery TLFP-14BR 12V

Replace Lead-Acid Battery Type
YTZ10S, YTB-BS, YT1B-BS, YTX14AH-BS, YB10A-A2, YB12A-A, YB12A-B, YB12B-B2, YB12C-A, YB14-A2, YB14-B2, YB14A-A1, YB14A-A2, 12N12A-4A-1

Specification
Weight 942gr (Battery Only)
Voltage 12v - 48wh
Capacity 4Ah
CCA 280
Charge Current Standard 2A Maximum 8A
Dimension 13.5 x 5.5 x 9.5 cm

Product Code: 22101-IRON1-TLFP3
Dimension: 16 x 18.3 x 9.5 cm
Weight: 1.17 kg

TDR High Performance Lithium Battery 12v 2.5Ah (4S1P)
Specification
Weight 496gr (Battery Only)
Voltage 13.2v
Capacity 31.7Wh, 2.5Ah
CCA 120
Dimension 11.4 x 4 x 8 cm (Battery Only)

Product Code: 22101-ALL01-L1225
Dimension: 13 x 6 x 12 cm
Weight: 0.61 kg

TDR Lithium Iron Phosphate (LiFePO4) Battery TLFP-14BL 12V

Replace Lead-Acid Battery Type
YB10L-A2, YB10L-B, YB10L-B2, YTX14AHL-BS, YB10L-BP, YB12AL-A, YB12AL-A2, YB14L-A1, YB14L-A2, YB14L-B2, YB16AL-A2, SYB14L-A2, SYB14L-B2, 12N10-3A-2, 12N11-3A-1, 12N14-3A

Specification
Weight 934gr (Battery Only)
Voltage 12v - 48wh
Capacity 4Ah
CCA 280
Charge Current Standard 2A Maximum 8A
Dimension 13.5 x 6.5 x 9.5 cm (Battery Only

Product Code: 22101-IRON1-TLFP4
Dimension: 16 x 18.3 x 9.5 cm
Weight: 1.17 kg

TDR Lithium Iron Phosphate (LiFePO4) Battery TLFP-14R 12V

Replace Lead-Acid Battery Type
YTZ12S, YTZ14S, YTX12-BS, YTX12A-BS, YTX14-BS, YTX14H-BS, KMX14-BS

Product Code: 22101-IRON1-TLFP5
Dimension: 15.8 x 15.8 x 9.5 cm
Weight: 1.15 kg

TDR Lithium Iron Phosphate (LiFePO4) Battery TLFP-7L 12V

Replace Lead-Acid Battery Type
YTZ5S, YTZ7S, YTX4L-BS, YTX5L-BS, YTXL7L-BS, YB4L-A, YB4L-B, YB5L-B, YB6.5L-B YB7L-B, 12N4-3B, 12N5-3B, 12N5.5-3B, 12N7-3B, 12N7A-3A, 12N7CZ-3D, 12N7D-3B

Product Code: 22101-IRON1-TLFP1
Dimension: 12.7 x 13.7 x 7.7 cm
Weight: 0.68 kg

TDR Lithium Iron Phosphate (LiFePO4) Battery TLFP-9R 12V

Replace Lead-Acid Battery Type
YT7-BS, YT9-BS, YT-BS, YTX9-BS, YTR9-BS, YB9A-A, YB9-B, 12N9-4B-1

Product Code: 22101-IRON1-TLFP2
Dimension: 16 x 11.7 x 9.5 cm
Weight: 0.94 kg
